Salt recovery & drying

Agitated Thin Film Dryer

The last wet step. Concentrated liquor is spread as a thin film against a heated wall and dried to a handleable solid, closing the loop on liquid discharge.

The ATFD receives the highly concentrated slurry from the MEE. A heated jacket with a rotating agitator spreads the slurry as a thin film on the wall, removing the remaining moisture to produce a dry solid salt, while the water vapour goes to the condenser and fines are caught in a cyclone separator and collection bag.

An agitated thin film dryer takes the concentrated liquor from the evaporator and turns it into a dry solid. A rotor with hinged blades keeps the liquor as a thin, constantly renewed film against the jacketed wall, which gives a high heat transfer rate and a short residence time even for material that is heat sensitive or prone to fouling.

It is a compact unit for the duty it performs, and it is what allows a plant to say it discharges no liquid at all — the vapour is condensed and recovered, and the salt leaves as a solid for disposal or reuse.

An agitated thin film dryer with cyclone separator

Our scope

  • Receives concentrated slurry from MEE
  • Dries to a solid salt
  • Prevents scaling and fouling
  • Achieves zero liquid discharge
A containerised zero liquid discharge treatment plant

Typically supplied

  • Jacketed shell with rotor and hinged blades
  • Variable speed drive and gearbox
  • Vapour line and condenser
  • Salt discharge screw conveyor
  • Cyclone separator and solid collection bag
  • Bagging or collection station
  • Thermic fluid or steam heating circuit

Where it is used

  • Zero liquid discharge plants
  • Salt recovery from evaporator liquor
  • Heat sensitive and fouling streams

For drawings, sizing or a quotation on agitated thin film dryer, write to arun.saitradersengg@gmail.com or call +91 97509 55595.
