Reject concentration

Multiple Effect Evaporator

Concentrates RO reject and wastewater by evaporating water in multiple effects, with vapour from each effect heating the next. Steam economy across several effects boils the RO reject down to a concentrated liquor, with condensate recovered back as usable water.

The feed — RO reject or high-TDS wastewater — passes through the effects in turn. Vapour from one effect is used as the heat source for the next, which makes the system energy efficient, and the concentrated brine or slurry is sent on to the ATFD. It is the standard workhorse of ZLD plants in chemical, pharmaceutical and industrial wastewater treatment.

Once RO has taken out as much water as it can, what remains is a small, very concentrated stream. A multiple effect evaporator reuses the vapour from each effect as the heating medium for the next, which is what keeps the steam cost of concentrating that stream within reason.

We design and fabricate the effects, the thermal and steam side, and the condensate recovery that sends clean water back into the plant. Number of effects, falling film against forced circulation, and materials are chosen against your steam availability and the scaling behaviour of the liquor.

A three-effect multiple effect evaporator

Our scope

  • Design & fabrication
  • Steam & thermal systems
  • Condensate recovery
  • Installation & commissioning
Pressure vessels in a treatment building

Typically supplied

  • Falling film and forced circulation effects
  • Calandria and vapour separators
  • Surface or barometric condenser
  • Vacuum system
  • Circulation and transfer pumps
  • Condensate recovery tank
  • Steam pressure reducing station

Where it is used

  • RO reject concentration
  • Zero liquid discharge
  • Salt and chemical recovery
  • High TDS process streams

For drawings, sizing or a quotation on multiple effect evaporator, write to arun.saitradersengg@gmail.com or call +91 97509 55595.
